The ultimate flat roof skylight that provides abundant daylight and controllable ventilation. Features a solar panel that captures available daylight to recharge a highly efficient, concealed battery-powered operator and control system.

Product Features:

  • Wireless installation. No electrician required.
  • Maintenance Free – White PVC interior frame for a tough, hard wearing interior finish.
  • Outer aluminium cappings (grey).
  • Available in 6 sizes.
  • Remote control operation.
  • Rain sensor automatically closes the skylight when rain is detected.
  • High Performance double glazing as standard, with NEAT™ outer coating: reduces cleaning frequency.
  • Includes removable insect screen.
  • Requires custom-made flashing (not supplied by VELUX).
  • Approx 75% heat block

Wireless control system:

  • Radio frequency controller with advanced control options for both skylight and blind operation.
  • Rain sensor automatically closes the skylight once rain is detected.
  • Timer function included.
  • Home Automation Systems interface (KLF 200) available.

From $2024 incl. GST

flat roof solar skylight

Technical Performance

flat roof skylight pitch
flat roof skylight sizes
U-value †

Solar Heat Gain
Co-effecient †
Bushfire^

WERS max 5 stars
(summer rating)
Australian
standards
Skylight 2.90‡
Glass only 1.93
Skylight 0.24
Glass only 0.28
BAL40
AS4285#, AS1288
AS3959^, AS1530.1*



NB: VELUX recommends VCS is installed with a slight pitch (e.g. 3°-5°) to help prevent condensation build-up and water ponding on the glass. VCS skylights not suitable for VELUX Above-Below combination - contact VELUX for more information. U-value (W/m²K) and SHGC data based on AFRC simulations, (VCS complete skylight: size 1275mm x 1275mm). ^Skylight tested in closed position (VCS BAL assessed - based on VSS results), additional mesh protection may be required for opening apertures (consult local council). Roof pitch 0°-60°. #Cyclone test not performed with screws provided, installation requires #8 roofing screws. *Assessed in closed position.
BCA 2013 Vol 1 & 2 regulations (Prevention of Falls from Windows - Balustrades & Barriers): contact VELUX for information relating to restrictor devices for within-reach
opening skylights.
flat roof opening cross section
‡VCS must be installed with insulation and Gyprock, as shown (typical installation), to achieve 2.9 U-value rating.

1. Inner glass dimension
2. Internal lining eg: Gyprock
3. Timber base / upstand
4. Flashing
5. Insulation / thermal blanket
6. Inner throat dimension
7. Overall throat dimension

Instructions

Pre-installed programs

To make life easier and to get the most out of your skylight, your new remote is pre-installed with useful programs ready for use.

  • Indoor climate
  • Ventilation
  • Sun screening
  • Good night
  • Good morning
  • Leaving home
  • On vacation
  • Create your own
    Programmable skylight remote
